Product Description
Ga.Brad Nailers/Coil Nailers
16 - 18 Ga. Brad Nailers
- Molding & Decorative Trim
- Up hoistered & Trim Panels
- Picture Frame Assembly
- Cabinet Work
- Door & Window Casing
- Rattan
- Interior & External
- Furniture Trim.
Coil Nailers
- Sheathing
- Decking
- Sub flooring
- Create, Pallet
- Box assembly
- Magnesium Alloy Housing reduce weight
- Lost-wax casting precision in size, Special mterial for durability
- 360o adjustable exhaust port
- Ergonomical design for continuous operation
- High volume magazine holds up to 300 nails
- Adjustable depth of drive for precision nailing
- No mr rubber tip device.
Model
| Fastener Compatible Model
| Fastener
| Toll Specifications
|
Head Dia.
(mm (inch)
| Shank Dia.
mm (inch)
| Length
(mm)
| Shank Type
| Collated
| Pressure
| Load Capacity
| Dimensions
(H x W x L) (mm)
| Weight
(kg)
|
C-57P
| Max CN55
Bostitch N57C
| 5.0 ~ 5.7
(0.197" ~ 0.224")
| 2.1 ~ 2.3
(0.083" ~ 0.090")
| 25 ~ 57
| Smooth
Screw
Ring
| Wire
Plastic Sheet
| 5 ~ 7.5kg/cm2
75 ~ 110 psi
| 200 ~ 300 PCS
| 310 x 130 x 300
| 2.2
|
C-75PA
| Max CN-710
Bostitch N70CB
| 6.0 ~ 7.0
(0.236" ~ 0.275")
| 2.5 ~ 2.9
(0.090" ~ 0.114")
| 45 ~ 75
45 ~ 70
45 ~ 70
| Smooth
Screw
Ring
| 200 ~ 300 PCS
| 340 x 130 x 310
| 3.6
|
C-75PB
| 7.0
(0.275")
| 2.9 ~ 3.3
(0.114" ~ 0.129")
|
C-90PA
| Max CN85
Bostitch N86C | 7.0
(0.275")
| 2.9 ~ 3.8
(0.114" ~ 0.129")
| 50 ~ 90
50 ~ 83
50 ~ 83
| Smooth
Screw
Ring
| 150 ~ 300 PCS
| 365 x 130 x 310
| 3.7
|
C-90PB
|
| 7.0 ~ 7.5
(0.275" ~ 0.295")
| 3.3 ~ 3.8
(0.275" ~ 0.150")
|
C-100
| Bostitch N100C
| 6.0 ~ 7.5
(0.236" ~ 0.295")
| 2.9 ~ 3.8
(0.114" ~ 0.150")
| 50 ~ 100
50 ~ 90
50 ~ 90
| Smooth
Screw
Ring
| Wire
| 150 ~ 300 PCS
| 385 x 135 x 360
| 5.0
|
Model
| Fastener Compatible Model
| Fastener
| Tool Specifications
|
Nail Type
| Head Dia.
(mm)
| Shank Thickness
mm (inch)
| Shank Width
mm (inch)
| Length
(mm)
| Gauge
B.W.G.
| Pressure
| Load Capacity
| Dimensions
(H x W x L) (mm)
|
F18/35
| Bostitch BT35
| Brad
| 1.9
| 1.0 (0.04")
| 1.25 (0.05")
| 10 ~ 35
| 18
| 4 ~ 7kg/cm2
60 ~ 100 psi
| 100 PCS
| 210 x 59 x 260
|
F18/57
| Senco Finis Pro 25
| Brad
| 1.9
| 1.0 (0.04")
| 1.25 (0.05") | 15 ~ 57
| 18
| 4 ~ 7kg/cm2
60 ~ 100 psi
| 100 PCS | 260 x 59 x 250
|
F16/50
| Bea SK400
| Brad
| 2.8
| 1.4 (0.055")
| 1.6 (0.06")
| 20 ~ 50
| 16
| 4 ~ 7kg/cm2
60 ~ 100 psi | 100 PCS | 270 x 77 x 310
|
Precision and Power CombinedThese coil nailers are designed for precision and efficient operation in demanding environments. With adjustable torque and a resilient metal structure, professionals benefit from flexibility and powerful performance, whether on the assembly line or the building site.
Engineered Ergonomics and DurabilityBuilt with an ergonomic structure and reinforced housing, our coil nailers help reduce user fatigue and withstand stringent working conditions. The thoughtful design ensures that each tool stands the test of time, delivering productivity and user comfort in equal measure.
FAQs of Coil Nailers:
Q: How do I adjust the maximum torque on a pneumatic coil nailer?
A: You can adjust the maximum torque using the control dial or knob typically located on the tool. This allows you to tailor the force to match specific materials or application requirements, enhancing accuracy and safety.
Q: What materials and applications are coil nailers with a metal body suitable for?
A: Coil nailers with a metal body are highly suitable for heavy-duty applications involving wood, engineered panels, fencing, and pallets. Their robust construction ensures reliable performance in industrial, construction, and carpentry tasks.
Q: When is it beneficial to use a pneumatic coil nailer over other types?
A: Using a pneumatic coil nailer is most beneficial when consistent power and rapid nailing are required, especially for prolonged or high-volume tasks. Their compressed air operation ensures smooth function without frequent recharge interruptions.
Q: Where can I find reputable coil nailer suppliers, importers, and manufacturers in India?
A: We serve as a leading importer, manufacturer, supplier, trader, and wholesaler in India, offering high-quality coil nailers directly to businesses and professionals nationwide. Contact us for direct purchases or distribution inquiries.
Q: What is the process for operating a coil nailer safely and efficiently?
A: To operate a coil nailer safely, connect it to a compatible compressed air source, load the coil of nails securely, adjust the torque, and use proper personal protective equipment. Always follow the manufacturers guidelines for operation and maintenance.
Q: How does the ergonomic design benefit users of these coil nailers?
A: The ergonomic structure of our coil nailers reduces user fatigue, promotes better hand positioning, and improves maneuverability. This design is especially advantageous during extended periods of continuous work.
Q: What are the primary advantages of using coil nailers with a durable metal housing?
A: Coil nailers with durable metal housing offer increased longevity, decreased wear from daily use, and better protection for internal mechanisms. This ensures consistent performance and reduces the frequency of repairs or replacements.
